DVR 4CH Turbo HD H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 2MP HIKVISION/HiWatch HWD-5104MH

DVR 4CH Turbo HD H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 2MP   HIKVISION/HiWatch

HIKVISION/HiWatch DVR Καταγραφικό,4 καναλιών,Turbo HD.
• Ανάλυση 2 MP,κωδικοποίση βίντεο H.265+/H.265/H.264+/H.264.
• Σκληρός δίσκος τεχνολογίας Sata,χωρητικότητας 4 ΤΒ.
• Yποστήριξη σημάτων βίντεο HDTVI/AHD/HDCVI/CVBS.
• Τροφοδοσία 12 VDC/1,5 A.

Τεχνικά χαρακτηριστικά:

DVR
HWD-5104MH
Analog Video Input:
4-ch
HDTVI Input:
• 1080p25, 1080p30, 720p25, 720p30.
AHD Input:
• 1080p25, 1080p30, 720p25, 720p30.
HDCVI Input:
• 1080p25, 1080p30, 720p25, 720p30.
CVBS Input:
Support
IP Video Input:
 • 1-ch (Up to 5-ch) Up to 1080p Resolution.

• Support H.265+/H.265/H.264+/H.264 IP Cameras.
Audio Compression:
G.711u
Audio Input:
• 1-ch, RCA (2.0 Vp-p, 1 KΩ).

• 4-ch via Coaxial Cable.



HDMI/VGA Output:
• 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz.

• 1024 × 768/60Hz, HDMI/VGA Simultaneous Output.


Encoding Resolution:
• When 1080p Lite Mode not Enabled: 720p/WD1/4CIF/VGA/CIF.

• When 1080p Lite Enabled: 1080p Lite/HD 720p Lite/WD1/4CIF/VGA/CIF.
 Main Stream Frame Rate:
 • When 1080p Lite not Enabled: For 720p Stream Access: 720p/WD1/4CIF

• When 1080p Lite not Enabled: For 720p Stream Access:VGA/CIF@25 fps (P)/30 fps (N)

• When 1080p Lite Mode Enabled:1080p Lite/HD 720p Lite/WD1/4CIF/VGA

• When 1080p Lite Mode Enabled:CIF@25 fps (P)/30 fps (N)
Sub-Stream Frame Rate:
4CIF/ CIF/ QVGA@25 fps (P)/ 30 fps (N).
Video bit Rate:
32 Kbps to 4 Mbps.
Audio Output:
1-ch, RCA (Linear, 1 KΩ)
Audio bit Rate:
64 Kbps
Dual Stream:
Support
Stream Type:
Video, Video & Audio.
Synchronous Playback:
4-ch
Remote Connections:
32
Network Protocols:
• TCP/IP, PPPoE, DHCP, Hik-Connect, DNS

• DDNS, NTP, SADP, SMTP,NFS, iSCSI, UPnP™, HTTPS
SATA Interface:
1 SATA Interface.
Hard Disk Capacity:
Up to 4 TB Capacity for Each Disk.
Two-Way Audio Input:
Re-Use the First Audio Input.
Network Interface:
1, RJ45 10/100 Mbps Self-Adaptive Ethernet Interface.
USB Interface:
Rear Panel: 2 × USB 2.0
Power Supply:
12 VDC, 1,5 A
Consumption (Without HDD):
≤ 16 W
Working Temperature:
-10 °C ~ 55 °C
Working Humidity:
10% ~ 90%
Dimensions (W × D × H):
260 × 222 × 45 mm
Weight (Without HDD):
≤ 1 kg
